01 / Product briefing

Product Description

Review the intended use, key features, and technical information supplied for this product.

The Makita M8701ZB is an MT-series 26 mm combination (rotary) hammer with an SDS-Plus chuck and an 800 W motor delivering 2.3 J of impact energy. Three operating modes - rotation only, hammering with rotation, and hammering only - cover drilling, hole-making and light chipping, with a maximum drilling capacity of 26 mm in concrete. A variable speed trigger, reversing function and torque limiter make it suited to fit-out, mechanical and electrical, and general construction work.

Features and Benefits

3-mode operation: rotation only, hammering with rotation, and hammering only, for both drilling and chipping.
800 W motor delivers 2.3 J of impact energy (EPTA-Procedure 05/2009) and up to 26 mm drilling capacity in concrete.
SDS-Plus chuck allows quick one-touch bit changes.
Variable speed trigger lets the operator match speed to the material and bit size, with a reversing function.
Torque limiter cuts the drive if the bit jams, protecting the motor and reducing kickback risk.
Re-located operating mode lever for increased protection and durability.
Soft grip provides more comfort and control.
Double insulated.

Specifications

Model	M8701ZB
Chuck system	SDS-Plus
Continuous rating input	800 W
Impact energy (EPTA-Procedure 05/2009)	2.3 J
Capacity - concrete	26 mm
Capacity - steel	13 mm
Capacity - wood	32 mm
Capacity - core bit	68 mm
Capacity - diamond core bit (dry type)	80 mm
No load speed	0 - 1,200 rpm
Blows per minute	0 - 4,500 bpm
Operating modes	3 modes (rotation only / hammering with rotation / hammering only)
Dimensions (L x W x H)	362 x 71 x 194 mm
Net weight	2.7 kg
Sound pressure level	90 dB(A)

What's in the Box

M8701ZB Rotary Hammer x1
Side grip x1
Depth gauge x1

Note: the drill bit shown in the product photography is for illustration only and is not included.
